3.5mm ⇌ BMA(4 models)
| # | Model | Freq Range | Left Connector | Right Connector | VSWR |
|---|---|---|---|---|---|
| 1 | 3.5/BMA-KK | DC-18GHz | 3.5mm jack/female | BMA jack/female | <1.15 |
| 2 | 3.5/BMA-KJ | DC-18GHz | 3.5mm jack/female | BMA plug/male | <1.15 |
| 3 | 3.5/BMA-JK | DC-18GHz | 3.5mm plug/male | BMA jack/female | <1.15 |
| 4 | 3.5/BMA-JJ | DC-18GHz | 3.5mm plug/male | BMA plug/male | <1.15 |
