SMA Medium Through Wall(14 models)
| # | Model | L1 | L2 | ΦD1 | ΦD2 |
|---|---|---|---|---|---|
| 1 | SAFP-0304-F01 | 15mm/0.59" | 3mm/0.118" | 2.1mm/0.083" | 0.64mm/0.025" |
| 2 | SAFP-0103-F01 | 3.2mm/0.126" | 1.27mm/0.05" | 2.2mm/0.087" | 0.30mm/0.012" |
| # | Model | L1 | L2 | ΦD1 | ΦD2 |
|---|---|---|---|---|---|
| 1 | SAFP-0304-F02 | 15mm/0.59" | 3mm/0.118" | 2.1mm/0.083" | 0.64mm/0.025" |
| 2 | SAFP-0103-F02 | 3.2mm/0.126" | 1.27mm/0.05" | 2.2mm/0.087" | 0.30mm/0.012" |
| # | Model | L1 | L2 | ΦD1 | ΦD2 |
|---|---|---|---|---|---|
| 1 | SAFP-0304-F04 | 15mm/0.59" | 3mm/0.118" | 2.1mm/0.083" | 0.64mm/0.025" |
| 2 | SAFP-0103-F04 | 3.2mm/0.126" | 1.27mm/0.05" | 2.2mm/0.087" | 0.30mm/0.012" |
| # | Model | L1 | L2 | ΦD1 | ΦD2 |
|---|---|---|---|---|---|
| 1 | SAFP-0304-F05 | 15mm/0.59" | 3mm/0.118" | 2.1mm/0.083" | 0.64mm/0.025" |
| 2 | SAFP-0103-F05 | 3.2mm/0.126" | 1.27mm/0.05" | 2.2mm/0.087" | 0.30mm/0.012" |
| # | Model | L1 | L2 | ΦD1 | ΦD2 |
|---|---|---|---|---|---|
| 1 | SAFP-0304-F06 | 15mm/0.59" | 3mm/0.118" | 2.1mm/0.083" | 0.64mm/0.025" |
| 2 | SAFP-0103-F06 | 0.30mm/0.012" | 1.27mm/0.05" | 2.2mm/0.087" | 0.30mm/0.012" |
| # | Model | L1 | L2 | T | ΦD1 | ΦD2 |
|---|---|---|---|---|---|---|
| 1 | SAFP-0813-F01 | 3mm/0.118" | 1.5mm/0.06" | 0.2mm/0.008" | 4.1mm/0.162" | 1mm/0.04" |
| 2 | SAFP-0713-F01 | 4mm/0.158" | 1.5mm/0.06" | 0.2mm/0.008" | 4.1mm/0.162" | 1mm/0.04" |
| # | Model | L1 | L2 | T | ΦD1 | ΦD2 |
|---|---|---|---|---|---|---|
| 1 | SAFP-0813-F04C | 3mm/0.118" | 1.5mm/0.06" | 0.2mm/0.008" | 4.1mm/0.162" | 1mm/0.04" |
| 2 | SAFP-0713-F04C | 4mm/0.158" | 1.5mm/0.06" | 0.2mm/0.008" | 4.1mm/0.162" | 1mm/0.04" |
